Description
Cam-17 Universal Reverse Camera
Universal, Fixed Angle Mounted, Drill to Fit Reverse Camera for Horizontal Surfaces. With 1099 HD Sensor, 480 TV Lines and 976 x 496 Resolution. Mirror/Normal Image Adjustment. Minimum Illumination: 0.1 Lux. Video Output: 1.0V p-p 75ohm. Operating Voltage: 12V DC.
Features & Benefits
- Universal; Compatible with all vehicles
- Image Sensor: 1099 HD CCDTV
- TV Lines: 560
- Resolution: 976 x 496
- Minimum Illumination: 0.1 Lux
- TV System: NTSC
- Waterproof Rating: IP68
- Horizontal Angle: 170 Degrees
- Vertical Angle: 120 Degrees
- Parking Lines: Yes (Removable)
- Image Adjustment: Yes (Mirror/Normal)
- Enhanced Performance In Low Light: Yes
- Video Output: 1.0V p-p 75ohm
- Operating Voltage: 12V DC (Negative Ground)
- Current Consumption: 120mA @ 13.8V
- Operating Temperature: -20 Degrees C to +70 Degrees C
