Audison bit DMI Signal Interface Sound Processor

Description

Audison bit DMI Signal Interface Sound Processor

As vehicle manufacturers adopt the MOST serial bus management system in their vehicles, it has become increasingly important to find ways to grab and transport their perfectly good digital audio signals to an on-board signal processor or amplifier with a digital input in order to ensure the upmost signal integrity. This in turn enables car owners to upgrade their car audio while maintaining full functions of the vehicle’s on-board systems. The bit DMI can pick up the vehicle’s MOST signal at any connection point and convert it to a TOSLINK optical output. With many MOST equipped vehicles now handled by this fantastically versatile interface, the future of great sounding car audio is preserved and drivers may once again choose the audio upgrades of their choice.

Product Features:

• Voltage 8 – 18 VDC
• Idling current 150 mA
• Switched off < 5 mA
• Remote IN Automatic turn On/Off via MOST
• Remote OUT 12 VDC (200 mA)
• MOST optical input MOST IN/OUT socket connector
• TOSLINK optical output S/PDIF max 48 kHz/16 bit PCM
• From/to personal computer 1 x USB Mini B to A (2.0)
• PC connection USB-A socket (1.1/2.0/3.0)
• Software/PC requirements Microsoft Windows (32/64 bit):
• XP, Vista, Windows 7, Windows 8
• Graphic card min. resolution: 800 x 600
• Ambient temperature range Operating: -40 °C to 100 °C
• W x H x D (mm) 141.5 x 36.5 x 86.5
• Weight (kg ) 0.26
